IEC 62196 Type 2 Female EV Charging Socket 1/3phase 16A/32A Type 2 EV Socket

The Type 2 EV Socket (also known as Mennekes connector) is the mainstream European standard for AC charging of electric vehicles and is widely used in homes, public charging stations and commercial locations. Designed for efficiency, safety and compatibility, it supports both single-phase and three-phase AC charging and is compatible with most major EV brands (e.g. Tesla, BMW, Volkswagen, Audi, etc.), making it one of the core components of the future sustainable transportation infrastructure.

1
1
1
1
Contact Us

Specifications of IEC 62196 Type 2 Female EV Charging Socket 1/3phase 16A/32A Type 2 EV Socket

Technical Information
Electrical Performance
Rated current16A/32A
Operation voltage250/415V
Insulation resistance＞1000MΩ（DC500V）
Terminal temperature rise＜50K
Withstand Voltage2000V
Contact Resistance0.5mΩ Max
Applied Materials
Case MaterialThermoplastic,flame retardant grade UL94 V-0
Conntact bushCopper alloy,silver plating
Environmental performance
Operating temperature-30°C~+50°C
Mechanical properties
Mechanical lifeno-load plug in/pull out＞10000 times
Coupled insertion force>45N<80N





Functionality Introduction of IEC 62196 Type 2 Female EV Charging Socket 1/3phase 16A/32A Type 2 EV Socket


Features

Our Type 2 EV Socket is more than just a connector; it's your gateway to a faster, safer, and smarter EV charging experience.

  • Meet 62196-2 IEC 2010 SHEET 2-IIa standard

  • Nice appearance，up flip protection,support front and back installation

  • Reliability of materials, antiflaming,pressure -resistant,abrasion resistance,impact resistance and high oil

  • Excellent protection performance,protection grade IP44(working condition)
