16A 32A Type 2 IEC62196 Female Plug with Spiral Cable

Name: 16A 32A Type 2 IEC62196 Female Plug with Spiral Cable
Brand: XTECK NEW ENERGY TECHNOLOGY CO., LTD.
Price: 200 USD
Availability: InStock

The Type 2 Tethered Cable is a high-performance charging cable designed for electric vehicles (EVs) that use the Type 2 (IEC 62196) connector. It is widely recognized as the standard charging solution for EVs in Europe and other regions, offering a reliable, safe, and efficient way to charge your vehicle at home, work, or public charging stations.

Contact Us

Specifications of 16A 32A Type 2 IEC62196 Female Plug with Spiral Cable

Technical Information
Type	Type 2
Rated Voltage	250V / 480V AC
Rated Output Current	16A single-phase / 16A three-phase 32A single-phase / 32A three-phase
Standard	EN 62196-2: 2017
Rated Frequency	50Hz
Protection Grade	IP65 (coupled state)
Conductor Material	Copper alloy, silver plated
Shell Material	PC ( UL94 V0)
Working Temperature	-30℃~+50℃
Storage Temperature	-30°C to 85°C
Insulation Resistance	＞10MΩ
Terminal Heats Up	＜50K
Pressure Resistance	＞2000VAC
Mechanical Life	No-load plugging＞＞10000 times
Altitude	＜2000M

Functionality Introduction of 16A 32A Type 2 IEC62196 Female Plug with Spiral Cable

Features

Compatibility

Type 1 Connector: Designed for EVs with a Type 1 (SAE J1772) port, such as Nissan Leaf, Mitsubishi Outlander PHEV, and Chevrolet Volt.

Universal Use: Compatible with most Level 1 and Level 2 charging stations, ideal for home and public charging.

Charging Speed

Level 1: Supports 120V AC charging for overnight home use.

Level 2: Delivers 240V AC charging, up to 7.4kW, adding 20-30 miles of range per hour.

Durability & Safety

Robust Materials: Weather-resistant construction for outdoor use.

Safety Features: Overcurrent, overvoltage, and overheating protection.

Tethered Design: Reduces wear and tear, ensuring a secure connection.

Ease of Use

Plug-and-Play: Simple connection to EVs and charging stations.

Compact & Lightweight: Easy to handle and store.

LED Indicators: Clear charging status updates.

Applications

Home Charging: Perfect for wall-mounted home stations.

Public Charging: Compatible with public Level 2 stations.

Workplace Charging: Ideal for daily commutes and workplace setups.
