60kW 90kW 120kW DC Charging Station OCPP1.6 Floor Mounted Advertising EV Charging Station 55 inch screen

Name: 60kW 90kW 120kW DC Charging Station OCPP1.6 Floor Mounted Advertising EV Charging Station 55 inch screen
Brand: XTECK NEW ENERGY TECHNOLOGY CO., LTD.
Price: 200 USD
Availability: InStock

This advanced multi-standard fast charger delivers flexible power options (60kW/90kW/120kW) with full compatibility across GB/T, CCS, CHAdeMO, and NACS protocols. The integrated 55-inch high-brightness digital display serves as a premium advertising platform, creating continuous revenue streams. Engineered for commercial-grade reliability, it maintains uninterrupted 24/7 operation in extreme environments (up to 55°C) through its innovative multi-fan cooling architecture with 50% greater airflow than industry standards.

Smart power management enables simultaneous dual-port charging without performance degradation, while OCPP 1.6J/2.0.1 certification guarantees seamless integration with any charging network.

60kW 90kW 120kW DC Charging Station OCPP1.6 Floor Mounted Advertising EV Charging Station 55 inch screen

Contact Us

Specifications of 60kW 90kW 120kW DC Charging Station OCPP1.6 Floor Mounted Advertising EV Charging Station 55 inch screen

Technical Information
Technical Data
Power	60kW/90kW/120kW
Input Voltage	400V±15%/440V±10%/480V±10%
Input Voltage Type	TN-S
Working Frequency	45~65Hz
Power Factor	≥0.99
Efficiency	≥94%
Rated Voltage	CHAdeMO 500Vdc; CCS 1000Vdc; GBT 1000Vdc
Output Current	CHAdeMO 125A; CCS1/CCS2 200A; GBT 250A
Design
Dimension(W x D x H)	870mm610mm2037mm
Charging Ports	Dual Ports
Cable Length	5m or 7m
UI
Advertising Screen	55''LCD
AD Machine Brightness	2500cd/m²
User Interface Display	8'' LCD Touch Screen
Language	Chinese, English, French, German, Spanish, Russian, etc.(Customized)
Payment	Mobile APP/RFID
Network Connection	4G/Ethernet
Communication Protocols	OCPP1.6J
Physical and Environmental Data
Working Temperature	-30°C ~ +50°C
Storage Temperature	-35°C ~ +55°C
Operating Humidity	≤95% Non-Condensing
Protection	P54
Acoustic Noise	<60dB
Cooling Method	Forced Air-Cooling
Emergency Stop	Yes
Customization Options
Dehumidifier	Yes
Heater	Yes

Key Product Advantages of 60kW 90kW 120kW DC Charging Station OCPP1.6 Floor Mounted Advertising EV Charging Station 55 inch screen

Universal Fast Charging

Supports GB/T, CCS, CHAdeMO, and NACS standards - compatible with most EV models worldwide.

Smart Advertising Revenue

Features a 55-inch LCD display that functions as a digital billboard, generating passive income for operators.

Extreme Environment Reliability

Enhanced cooling system (50% more fans + enlarged vents) ensures 24/7 full-power operation even at 55°C.

Dual-Vehicle Fast Charging

Dynamic load balancing technology enables simultaneous charging for two EVs without power reduction.

Open Platform Compatibility

OCPP 1.6J/2.0 certified for seamless integration with various management systems.

Extended Warranty Protection

Comes with 26-month base warranty + optional extensions for long-term operation security.
