7kW 15kW 20kW 30kW 40kW CCS1 CCS2 GBT CHAdeMo Portable DC EV Charger

This portable DC EV charger is compact, lightweight, and easy to carry. Its unique ventilation design separates hot and cold air, improving heat exchange efficiency and ensuring more stable performance, while also making maintenance easier. It is compatible with most electric vehicles worldwide. The charger features multiple protection functions, including IP44 and IK10 protection ratings, as well as power recovery, low voltage, overcurrent, over-temperature, short circuit, surge, grounding detection, and emergency shutdown, ensuring a safe and reliable charging experience.

juicebox-connected-wallbox
juicebox-wallbox

Specification of 7kW 15kW 20kW 30kW 40kW CCS1 CCS2 GBT CHAdeMo Portable DC EV Charger

Technical Information
StandardCCS1 CCS2 GBT CHAdeMo
Input Voltage260-475V
Frequency50-60Hz
Output VoltageDC 200-1000V
Input Current30A
Output Current60A
Rated Power20kW
Size645×300×235(The latest model shall prevail)
Weight44kg
Work Efficiency95%
Auxi liary source12V( 24V optional)
Operating Temperature-20℃~+50℃
Humidity≤3000m
Protection GradeIP44
Input Line Length5M (Or Customization)
Gun Cable Lenth3M (Or Customization)
StandardGB/T 20234 /IEC 61851/SAE J1772 / CHADEMO 2.0


Functionality Introduction of 7kW 15kW 20kW 30kW 40kW CCS1 CCS2 GBT CHAdeMo Portable DC EV Charger

Features and Functions:

  • Multiple Power Options: This portable DC charger offers a range of power options, including 7kW, 15kW, 20kW, 30kW, and 40kW, catering to different electric vehicle charging needs. Users can select the appropriate power level based on their specific requirements.

  • Multifunctional Compatibility: The charger supports various plug types, including CCS, GBT, and CHAdeMO, ensuring compatibility with electric vehicles that meet CCS1, CCS2, and GB/T standards.

  • Advanced Safety Features: With an IP44 rating, the charger is designed to prevent dust and water ingress, ensuring safe operation in various environments. Additionally, it is CE, CB, TUV, and UKCA certified, meeting international safety standards.

  • Convenient Connectivity Options: The charger offers basic, app, and Bluetooth connectivity, enabling users to remotely monitor and control the charging process, receive notifications, and access detailed charging data, making it an ideal solution for users who prioritize convenience and ease of use.

  • Other Support: The charger comes with a customizable 5-meter cable, allowing users to select the most suitable length for their needs. It is durable, backed by a 24-month warranty, and built to withstand regular use.
